Open Type Robust Commercial Diesel Generator Set Around 150kw

After-sales Service:	Yes
Warranty:	3 Months to One Year
Type:	Basic Diesel Generator

Customization:	Available

Basic Info.

Model NO.	YG-150GF	Installation Method	Fixed
Stroke	Four Stroke	Cooling Method	Water Cooling
Output Type	AC Three Phase	Speed	Speed
Conditions of Use	Land Use	Usage	Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit	Ordinary	Excitation Mode	AC Rotating Exciter
Transport Package	Plywood Case Packing for Open Type	Specification	LARGE
Trademark	YAG	Origin	China
HS Code	850213	Production Capacity	3000sets

Product Description

Technical specification parameters of 150KW series diesel generator set
Unit model	YAG-150GF	Rated power	150KW
Rated output voltage	230V/400V	Rated power factor	0.8
Rated current	270A	Insulation grade	H
Rated speed	1500/1800rpm	Protection grade	IP22
Rated frequency	50/60HZ	Overall dimension (mm)	24007501200
Voltage Control Methods	AVR	Overall weight	1050KG
Technical specification parameters of diesel engine
Brand	YAG	Model	R6105IZLD
Cylinders	6	Speed	1500/1800rpm
*Bore stroke(mm)**	105*125	Power	1151KW
Displacement	6.49	Fuel consumption rate	209g/kwh
Type	Straight line, four stroke	Lubrication mode	Pressure and splash type
Intake mode	Turbo charged	Start-up mode	24V DC electric start
speed regulation	Mechanical speed regulation	Cooling mode	Closed water cooling
Technical specification parameters of alternator
Rated power	150KW	Type	Brushless
Insulation grade	H	Protection grade	IP22
Phase	3-Phase,4-wire	Voltage Control Methods	AVR

Quality & Testing
1. All the raw materials/parts by IQC (Incoming Quality Control) before launch into process.
2. Each generator/part under control of IPQC (Input Process Quality Control).
3. Each generator/part must be pass 100% inspection between process.
4. All-sided ex-factory testing in various condition (Outgoing Quality Control).

Advantages
1. Ten years dedicated in diesel generator with rich experience.
2. 7-15 days quick delivery, annual output 50,000 sets.
3. Competitive price, huge material/parts sourcing, large scale production.
4. Lower noise 70-73 db at 7 m, super silent as 60-65 db at 7 m.
5. Spare parts and consumable service available.
6. Customized & OEM available.
7. One stop and 7×24 service.
8. Excellent technical support and service.

FAQ

Q1: Are you a manufacture factory or trade company?
A1: We are the manufacturer factory specialized in diesel generator set industry for many years already. Annual output 20,000sets, products/service reach 40 countries and regions.

Q2: How to control quality?
A2: 1) All the raw materials/parts by IQC (Incoming Quality Control) before launch into the process. 2) Each process under control of IPQC (Input Process Quality Control). 3) Each generator set/part must be pass 100% inspection between process. 4) All-sided ex-factory testing in various condition (Outgoing Quality Control).

Q3. How about your price level?
A3: Our price is reasonable which is based on quality and cost. And it’s negotiable which based on quality or exact demands. It’ll be much helpful if more details could be provided when you make an inquiry.

Q4: Delivery time?
A4: 7-15 days after deposit received. Most of the diesel generator sets/parts with stock, we can make delivery immediately or make out in short time.

Q5. How about MOQ?
A5: MOQ is 1 set.

Q6. OEM/Customized available?
A6: Welcome, generator set could be customized made according to client demands. Own design/LOGO on generator set available as well.

Q7. Payment term?
A7: 30% T/T as deposit, balance should be release 10 days before shipment. Or 100% L/C at sight.
