30kw Diesel Generator Set for Home Use

Warranty: 1 Year / 1000 Running Hours
Type: Basic Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Output Type: AC Three Phase
Customization:
Available

Basic Info.

Model NO. YG-30GF Excitation Mode AC Rotating Exciter
Speed Low Speed Transport Package Plywood Case
Conditions of Use Land Use Trademark yag
Usage Common Units, Standby Unit, Emergency Crew Origin Weifang
Landuse Type of Unit Ordinary HS Code 8502110000



Product Description

cheap 4100 Series diesel generator 40 kva 30kw
Technical specification parameters of
30KW diesel generator set
Unit model
YG-30GF
Rated power
30KW
Rated output voltage
230V/400V(
Rated power factor
0.8
Rated current
54A
Insulation grade
H
Rated speed
1500/1800rpm
Protection grade
IP22
Rated frequency
50/60HZ
Overall dimension (mm)
1800*700*1200
Voltage Control Methods
AVR
Overall weight
500KG
Technical specification parameters of diesel engine
Brand
YAG
Model
K4100D
Cylinders
4
Speed
1500/1800rpm
Bore * stroke(mm)
100*115
Power
30.1KW
Displacement
3.6
Fuel consumption rate
228g/kwh
Type
Straight line, four stroke
Lubrication mode
Pressure and splash type
Intake mode
Turbo charged, air to air cooled
Start-up mode
24V DC electric start
Speed regulation
Mechanical speed regulation
Cooling mode
Closed water cooling
Technical specification parameters of alternator
Rated power
30KW
Type
Brushless
Insulation grade
H
Protection grade
IP21/22/23
Phase
3-Phase,4-wire
Voltage Control Methods
AVR
