| Model NO. | YG-120GF | Excitation Mode | Static Exciter |
| Speed | Low Speed | Transport Package | Plywood Case |
| Conditions of Use | Land Use | Trademark | yag |
| Usage | Common Units, Standby Unit, Emergency Crew | Origin | Weifang |
| Landuse Type of Unit | Low Noise | HS Code | 8502120000 |
| Transport Package | Plywood Case Packing for Open Type | Specification | LARGE |
| Trademark | YAG | Origin | China |
| HS Code | 850213 | Production Capacity | 3000sets |
120kw diesel generator open type silent 380v 400v 440v 30v Generator Genset Set
|
Technical specification parameters of 120KW diesel generator set
|
|||
|
Unit model
|
YC-120GF
|
Rated power
|
120KW
|
|
Rated output voltage
|
230V/400V
|
Rated power factor
|
0.8
|
|
Rated current
|
540A
|
Insulation grade
|
H
|
|
Rated speed
|
1500/1800rpm
|
Protection grade
|
IP22
|
|
Rated frequency
|
50/60HZ
|
Overall dimension (mm)
|
2500*850*1300
|
|
Voltage Control Methods
|
AVR
|
Overall weight
|
2350KG
|
|
Technical specification parameters of diesel engine
|
|||
|
Brand
|
With YUCHAI engine
|
Model
|
YC6B180L-D20
|
|
Cylinders
|
6
|
Speed
|
1500/1800rpm
|
|
Bore * stroke(mm)
|
108*125
|
Power
|
132KW
|
|
Displacement
|
6.87
|
Fuel consumption rate
|
195g/kwh
|
|
Type
|
Straight line, four stroke
|
Lubrication mode
|
Pressure and splash type
|
|
Intake mode
|
Turbo charged
|
Start-up mode
|
24V DC electric start
|
|
speed regulation
|
Electronic speed regulation
|
Cooling mode
|
Closed water cooling
|
|
Technical specification parameters of alternator
|
|||
|
Rated power
|
120KW
|
Type
|
Brushless
|
|
Insulation grade
|
H
|
Protection grade
|
IP22
|
|
Phase
|
3-Phase,4-wire
|
Voltage Control Methods
|
AVR
|
